  3. 175.510.080.130
175.510.080.130 175.510.080.130 175.510.080.130 175.510.080.130 Plug diagram for 175.510.080.130
175.510.080.130
A2TG0391+
A130.569
[ALT31137] Alternator Subaru 80A
175.510.080.130 supersedes:
WOOALT31137


Additional Details

BrandPLO

Unit of IssueEACH

Weight5.020kg

Intrastat8511500090

CoOCN

Property Value
Brand+Line Original
Voltage (V)12
Amperage (A)80
Pulley Diameter (mm)54.9
B+ Terminal (30)M8
Plug Code172
Alternator DesignIF/IR
OE ManufacturerMITSUBISHI
Vehicle ManufacturerSUBARU
OEM OEM Reference BOM
BOSCH 0986045741
BOSCH 4574
LUCAS LRA02102
LUCAS LRA2102
MITSUBISHI A002TB3091
MITSUBISHI A002TB5391
MITSUBISHI A002TG0391
MITSUBISHI A2TB3091
MITSUBISHI A2TB5391
MITSUBISHI A2TG0391
SUBARU 23700AA380
SUBARU 23700AA420
SUBARU 23700AA540
Make Model Type Year Info
SUBARU FORESTER 2.0 1997 - 2002 1994cc, 4cyl, 122HP
SUBARU FORESTER 2.0 1998 - 2002 1994cc, 4cyl, 125HP
SUBARU FORESTER 2.0 2002 - 1994cc, 4cyl, 125HP
SUBARU FORESTER 2.0 S Turbo 1998 - 2001 1994cc, 4cyl, 170HP
SUBARU FORESTER 2.0 S Turbo 2001 - 2002 1994cc, 4cyl, 177HP
SUBARU FORESTER 2.0 S Turbo 2002 - 1994cc, 4cyl, 177HP
SUBARU FORESTER 2.5 2003 - 2457cc, 4cyl, 211HP
SUBARU FORESTER 2.5 2005 - 2012 2457cc, 4cyl, 175HP
SUBARU FORESTER 2.5 2005 - 2457cc, 4cyl, 232HP
SUBARU FORESTER 2.5 2008 - 2457cc, 4cyl, 171HP
SUBARU FORESTER 2.5 AWD 1997 - 2002 2457cc, 4cyl, 167HP
SUBARU FORESTER 2.5 AWD 2002 - 2005 2457cc, 4cyl, 152HP
SUBARU FORESTER 2.5 AWD 2008 - 2457cc, 4cyl, 230HP
SUBARU FORESTER 2.5 AWD 2009 - 2457cc, 4cyl, 171HP
SUBARU FORESTER 2.5 AWD 2011 - 2498cc, 4cyl, 171HP
SUBARU FORESTER 2.5 All-wheel Drive 2005 - 2457cc, 4cyl, 165HP
SUBARU FORESTER 2.5 RX Nato AWD 2002 - 2005 2457cc, 4cyl, 156HP
SUBARU FORESTER XS 2009 - 2457cc, 4cyl, 171HP
SUBARU FORESTER XS 2011 - 2498cc, 4cyl, 171HP
SUBARU IMPREZA 1.5 2001 - 2005 1493cc, 4cyl, 101HP
SUBARU IMPREZA 1.5 2001 - 2005 1498cc, 4cyl, 101HP
SUBARU IMPREZA 1.5 2005 - 1498cc, 4cyl, 110HP
SUBARU IMPREZA 1.5 2008 - 1498cc, 4cyl, 107HP
SUBARU IMPREZA 1.5 AWD 2005 - 1498cc, 4cyl, 110HP
SUBARU IMPREZA 1.5 AWD 2006 - 1498cc, 4cyl, 105HP
SUBARU IMPREZA 1.5 AWD 2008 - 1498cc, 4cyl, 107HP
SUBARU IMPREZA 1.5 F 2008 - 1498cc, 4cyl, 107HP
SUBARU IMPREZA 1.5 L 1995 - 1998 1493cc, 4cyl, 95HP
SUBARU IMPREZA 1.5 L 1998 - 2000 1493cc, 4cyl, 90HP
SUBARU IMPREZA 1.6 1993 - 1998 1597cc, 4cyl, 90HP
SUBARU IMPREZA 1.6 1996 - 2000 1597cc, 4cyl, 90HP
SUBARU IMPREZA 1.6 1998 - 2000 1597cc, 4cyl, 95HP
SUBARU IMPREZA 1.6 2001 - 2006 1597cc, 4cyl, 95HP
SUBARU IMPREZA 1.6 AWD 1996 - 2000 1597cc, 4cyl, 90HP
SUBARU IMPREZA 1.6 AWD 2000 - 1597cc, 4cyl, 95HP
SUBARU IMPREZA 2.0 AWD 1995 - 2000 1994cc, 4cyl, 115HP
SUBARU IMPREZA 2.0 AWD 1998 - 2000 1994cc, 4cyl, 280HP
SUBARU IMPREZA 2.0 AWD 2000 - 1994cc, 4cyl, 125HP
SUBARU IMPREZA 2.0 AWD 2005 - 1994cc, 4cyl, 250HP
SUBARU IMPREZA 2.0 AWD 2005 - 1994cc, 4cyl, 280HP
SUBARU IMPREZA 2.0 WRX STi AWD 2001 - 1994cc, 4cyl, 265HP
SUBARU IMPREZA 2.0 WRX STi AWD 2004 - 1994cc, 4cyl, 320HP
SUBARU IMPREZA 2.0 WRX STi AWD 2005 - 1994cc, 4cyl, 280HP
SUBARU IMPREZA 2.0 WRX STi All-wheel Drive 2002 - 2005 1994cc, 4cyl, 265HP
SUBARU IMPREZA 2.0 WRX Turbo AWD 2000 - 1994cc, 4cyl, 218HP
SUBARU IMPREZA 2.0 WRX Turbo AWD 2002 - 1994cc, 4cyl, 225HP
SUBARU IMPREZA 2.0 i 1996 - 1998 1994cc, 4cyl, 116HP
SUBARU IMPREZA 2.0 i 1998 - 2000 1994cc, 4cyl, 125HP
SUBARU IMPREZA 2.0 i AWD 1995 - 2000 1994cc, 4cyl, 115HP
SUBARU IMPREZA 2.0 i AWD 1995 - 2000 1994cc, 4cyl, 116HP
SUBARU IMPREZA 2.0 i AWD 1998 - 2000 1994cc, 4cyl, 125HP
SUBARU IMPREZA 2.0 i AWD 2000 - 1994cc, 4cyl, 125HP
SUBARU IMPREZA 2.0 i AWD 2001 - 2002 1994cc, 4cyl, 204HP
SUBARU IMPREZA 2.0 i All-wheel Drive 2002 - 2007 1994cc, 4cyl, 125HP
SUBARU IMPREZA 2.0 i All-wheel Drive 2005 - 2007 1994cc, 4cyl, 160HP
SUBARU IMPREZA 2.0 i R AWD 2005 - 1994cc, 4cyl, 160HP
SUBARU IMPREZA 2.0 i WRX 1998 - 2000 1994cc, 4cyl, 280HP
SUBARU IMPREZA 2.0 i WRX AWD 2002 - 2005 1994cc, 4cyl, 228HP
SUBARU IMPREZA 2.0 i WRX All-wheel Drive 2002 - 2005 1994cc, 4cyl, 228HP
SUBARU IMPREZA 2.5 AWD 2001 - 2005 2457cc, 4cyl, 177HP
SUBARU IMPREZA 2.5 AWD 2005 - 2457cc, 4cyl, 300HP
SUBARU IMPREZA 2.5 AWD 2007 - 2457cc, 4cyl, 270HP
SUBARU IMPREZA 2.5 AWD 2008 - 2457cc, 4cyl, 230HP
SUBARU IMPREZA 2.5 WRX AWD 2005 - 2457cc, 4cyl, 230HP
SUBARU IMPREZA 2.5 WRX STi AWD 2005 - 2457cc, 4cyl, 280HP
SUBARU IMPREZA 2.5 i WRX AWD 2005 - 2457cc, 4cyl, 230HP
SUBARU IMPREZA i 2000 - 1994cc, 4cyl, 125HP
SUBARU IMPREZA i WRX 1994 - 2000 1994cc, 4cyl, 211HP
SUBARU IMPREZA i WRX 1998 - 2000 1994cc, 4cyl, 218HP
SUBARU IMPREZA i WRX 1998 - 2000 1994cc, 4cyl, 280HP
SUBARU IMPREZA i WRX 2000 - 1994cc, 4cyl, 218HP
SUBARU IMPREZA i WRX 2008 - 2457cc, 4cyl, 230HP
SUBARU LEGACY 2.0 AWD 1998 - 2003 1994cc, 4cyl, 125HP
SUBARU LEGACY 2.0 AWD 2002 - 2003 1994cc, 4cyl, 280HP
SUBARU LEGACY 2.0 AWD 2003 - 1994cc, 4cyl, 138HP
SUBARU LEGACY 2.0 AWD 2005 - 1994cc, 4cyl, 165HP
SUBARU LEGACY 2.0 AWD 2005 - 1994cc, 4cyl, 179HP
SUBARU LEGACY 2.0 AWD 2005 - 1994cc, 4cyl, 190HP
